KELLYS Theos F90 SH 29"/27.5" 725Wh
Rahmen KELLYS THEOS F-series - Thermoplastic Hybrid Steel-Carbon Composite a.k.a. FEATHER® by Rein4ced assembled by advanced robotic manufacturing / Designed & manufactured in EUROPE / Think Link® suspension system, 170 mm rear travel, integrated removable battery, 1.8“ tapered HT, post mount 203 mm, mullet 29" / 27.5"+ wheelset, 12x148 mm Boost thru axle
Motor SHIMANO EP8, 85 Nm, 36 V
Akku KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by KELLYS-BMZ
Schalter SHIMANO SW-E7000-L for assist
Informations-Display SHIMANO SC-E7000
Gabel FOX 38 Float Factory, Kashima Coat (29) Boost, 180 mm, Float Evol / GRIP2 damper / 15QR thru axle
Dämpfer ROCK SHOX Super Deluxe Ultimate, DebonAir / RCT / Open-Threshold (230x65 mm)
Kurbelgarnitur SHIMANO Deore XT M8150 Hollowtech / CRE70 (34T) - length 170 mm
Schaltwerk SHIMANO Deore XT Di2 M8050 (direct mount)
Schalthebel SHIMANO Deore XT Di2 Shift Switch SW-M8050-R Firebolt
Gänge 11
Kassetenzahnkranz SHIMANO CS-M8000-11 (11-46T)
Kette KMC e11T (120 links)
Bremsen SHIMANO Deore XT M8120 Hydraulic Disc
Bremshebel SHIMANO Deore XT BL-M8100
Bremsscheiben SHIMANO MT800 203 mm front / SHIMANO EM810 203 mm rear
Laufräder DT SWISS H 1700 622x30 Center Lock front / DT SWISS H 1700 Spline 584x35 Center Lock rear
Vorderradreifen SCHWALBE Eddy Current Evo SuperTrail 65-622 (29x2.60) Tubeless Easy, ADDIX Soft, folding
Hinterradreifen SCHWALBE Eddy Current Evo Super Gravity 70-584 (27.5x2.80) Tubeless Easy, ADDIX Soft, folding
Steuersatz ACROS 1.8 tapered semi-integrated
Steckachse FOX 15QR 15x110 mm front / Mr.control 12x177 mm rear
Vorbau RACE FACE Aeffect R 35 - diam 28.6 mm / bar bore 35 mm / 0° / length 50 mm
Lenker RACE FACE Aeffect R 35 RiseBar - diam 35 mm / rise 20 mm / width 780 mm
Griffe KLS Poison
Sattelstütze FOX Transfer Factory Remote Telescopic, Kashima Coat - diam 30.9 mm / length 475 mm, travel 150 mm (M), 175 mm (L)
Sattel fi’zi:k Taiga, S-alloy rails
Pedale plastic
Rahmengrössen M / L
